TSM ThermoGUARD
TSM ThermoGUARD is a liquid thermal insulation coating based on acrylic polymers and ultra-fine ceramic microspheres (0.03-0.008 mm). It is applied like paint, forming a layer just a few millimeters thick, and functions as penetrating thermal insulation with a reflective effect.
The material reduces heat loss, increase the energy efficiency of buildings, and eliminates thermal bridging by acting as a balancing barrier between internal and external environments. It effectively prevents condensation, mold, mildew, corrosion, and protects surfaces from UV degradation.
Using TSM ThermoGUARD enables energy savings of 25-40% on heating, air conditioning, and electricity or gas consumption.
TSM ThermoGUARD - Innovative Liquid Thermal Insulation
- Energy savings: reduces heating, cooling, and electricity costs by 25-40%
- Applied like paint and simultaneously serves as insulation
- Reduces heat loss by up to 40%
- Prevents condensation, mold, mildew, corrosion, and UV-induced degradation
- Suitable for all types of structures: metal, concrete, brick, wood, as well as hard-to-reach areas (e.g., window slopes) and underfloor heating systems
- Eliminates cold bridging and structural freezing; protects concrete and brick from temperature-related damage
- White material, can be tinted and used as a finish coat
- Eco-friendly, water-based composition
- Easy to maintain and repair
- Non-combustible (Class A1)
- Operating temperature range: -60°C to +210°C
- Lightweight, does not add structural load
- Warranty: 20 years, subject to proper application
Technical Specifications
| Parameter | Value |
|---|---|
| Thermal Conductivity (λ) | 0.001 W/m·°C |
| Operating Temperature | -60°C to +210°C |
| Density (dry) | 380–580 kg/m3 |
| Density (liquid) | 470–690 kg/m3 |
| Vapor Permeability | 0.0014 mg/(m·h·Pa) |
| Specific Heat Capacity | 1.0 kJ/(kg·°C) |
| Adhesion to Metal | 1.53 MPa |
| Adhesion to Concrete/Wood | 1.84 MPa |
| Tensile Strength (after application) | 3.0 MPa |
| Tensile Strength (after 10 years) | 2.0 MPa |
| Impact Toughness | 50 kg·cm |
| Elongation at Break | 8% (stable after 10 years) |
Application Guidelines
Surface Preparation
Brick and Concrete
Remove surface dust.
Apply primer (recommended: TSM Primer).
Metal
Degrease surface (remove oil contaminants).
Clean areas affected by corrosion.
Apply a suitable primer according to metal type.
Wood
Remove dust.
Apply primer (recommended: TSM Primer).
Facade and Decorative Plasters
Remove surface dust.
Apply primer (recommended: TSM Primer).
Material Preparation
Mix thoroughly until a uniform consistenct is achieved.
Application
Apply by spray or brush in thin layers (approx. 0.35 mm per layer).
Minimum interval between layers: 2 hours.
Maximum thickness per 24 hours: 1 mm.
Number of layers depends on temperature, humidity, and on-site conditions (confirm with supplier/manufacturer).
Drying time: at +20°C and 50-60% humidity, a 1 mm layer dries in approx. 24 hours. In cold or humid conditions, drying time increases.
Consumption: ~1.4 L/m2 per 1 mm of coating thickness.
Packaging and Storage
20 L bucket (13 kg ±5%)
Do not stack pallets with buckets
Storage and transport: from +5°C to +25°C
Shelf life: 12 months
Service life over 30 years
Areas of Application
Private sector
TSM Ceramic brings professional-grade efficiency to your home
Architectural monuments
TSM Ceramic respects the past while building for the future.
Energy sector
TSM Ceramic — durable protection against heat, corrosion and environmental stress.
rail & rolling stock
TSM Ceramic - advanced anti-condensation & thermal protection for rail systems
